Handsome Beatrix Cro-moly City Bicycle Frameset
$ 449.95
Color
Princely Papyrus Shaving Cream Matte Anthracite Strawberry
Size
46cm 49cm 52cm 55cm
- 1 +

Building a city commuter as a single or three speed? That is exactly what the Beatrix was designed for. Because of it's slightly lower bottom bracket and longer wheel base, it’s the perfect frame for a commuter. Makes a great single speed, fixed gear, or 3 speed internal bike with it's 120mm rear facing dropouts. Braze-ons for front and rear racks and fenders as well as larger tire clearance make it a great choice for all year riding!

FRAMESET GEOMETRY CHART

Frame specs:

  • TIG Welded, 4130 Double Butted Cro-moly Main Triangle, 4130 Cro-moly Seat Stays, Mixte Stays, Chain Stays
  • 1-1/8” Headtube, 34mm Cup Size
  • 27.2 Seatpost Diameter
  • 30.0 Seat Collar Size (Seat Collar Included)
  • 68mm English Threaded Bottom Bracket Shell 1.37 x 24t
  • 120mm Rear Dropout Spacing, Rear Facing
  • 700c Wheel Size
  • 700 x 40 Tire Clearance Without Fenders
  • 700 x 38 Tire Clearance With Fenders (32 with tread)
  • Integrated Rear Cable Hanger
  • Brazed-On Cable Guides on Downtube and Chainstay
  • Rear Fender and Rack Mounts at Dropout
  • Rack Mounts on Seat Stays Near Seat Tube
  • Cantilever / Linear Pull Brake Bosses
  • Brazed-On Coaster Brake Tab
  • 52cm Weight: 5lb, 1oz



Fork specs:

  • 4130 Cro-moly Fork Blades, Crowned, TIG Welded
  • 30.0 Crown Race Sizing
  • 100mm Spacing
  • Front Fender and Rack Mounts
  • Mid Fork Blade Front Rack Mounts
  • 700c Wheel Size
  • 700 x 40 Tire Clearance Without Fenders
  • 700 x 38 Tire Clearance With Fenders
  • Cantilever / Linear Pull Brake Bosses
  • Weight: 2lb, 8oz
